High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage

USD $0.85/KG
High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage
Features Gallery Product Description Request A Quote
Name: Teardrop Pallet Rack
Color: RAL6000(Green), RAL5003(Blue), RAL2001(Red Orange), RAL2004(Pure Orange), RAL1037(Safety Yellow), Or Custom Color As Request
Usage: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
Beam Length: Up To 6000mm
Frame Height: Up To 12000mm
Load Capacity: 500-4000kg/layer
Material Type: High Strength Steel/American Standard Steel
High Light:

12m Teardrop Pallet Rack Systems


Heavy Duty Teardrop Style Pallet Rack


12m Teardrop Racking System

Basic Infomation
Place of Origin: China
Brand Name: Ironstone
Certification: RMI, CE, AS4084
Model Number: TDPR Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, Cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage




Teardrop Pallet Rack is the most extensively used pallet racking storage method in the United States. It is intended for quick and easy assembly without the need for clips or other fasteners. Green uprights and orange beams are the most common colors. In most cases, the sort of hole pitch is determined by your preferences. There are 76.2mm pitch pallet racking and 50mm pitch pallet racking available.



           High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 0





 Parameters of The Teardrop Pallet Rack



Name Teardrop (US) Pallet Rack Material American standard steel
Depth 24" - 60" Weight Capacity 1000-7000lbs/beam level
Width 48" - 156" Height 96" - 432" or Customized
Frame Structure Type Welded & Bolted 3" * 3" Upright frame with Seismic Baseplate
Beam Type 2.5" - 6.25" Step Beam
Beam Connector Type SP & SL Safety Locker
Surface finish Powder Coating & Galvanized
Application Environment Normal Temperature or Cold Room (Max -40C)
Certification RMI Certification,  ISO9001,  CE
Free Sample Available
OEM Available



Industry-Compatible Teardrop Rack


Our beam-to-column connection is intended to be compatible with various commonly available teardrop pallet rack systems, as well as slotted and structural pallet rack designs. When expanding your present pallet rack system, heavier bracing and higher impact resistance are ways to enhance rack reliability. Ironstone teardrop pallet rack system has an improved, sturdy, automated lock for increased security.




Teardrop Frames


High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 1




Teardrop systems are simple to assemble and have 2" vertical beam adjustments. There are no tools necessary. The teardrop beam-to-column connection is intended to be interoperable with other teardrop systems that are readily accessible.




High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 2




♦ Anchor holes that are offset


♦ A comprehensive set of profiles to optimize the solution


♦ Vertical adjustability of 2"


♦ Large base plates



♦ 6 bend columns


♦ 100% welded uprights





Teardrop Beams


High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 3



Interchangeable teardrop beams, like slotted beams, are available in a variety of profiles and lengths, with capacities of up to 18,000 lbs. per pair. Many existing systems, both old and new, can be integrated. Based on the minimum yield of steel, beams have a safety factor of 1.67. All beam capabilities are determined in accordance with current specifications.



High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 4



To increase security, our teardrop pallet system is equipped with a strong, proprietary automated lock. The components speed up installation and enhance safety by providing a positive beam-to-column connection.





Application & Options



► 100% Selective



Universal application



Industrial, retail, and general warehousing



Easily reconfigured



► Multitudes of accessories available



Versatile for inventory changes



Economical installation



Immediate access to every pallet load





   High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 5



Teardrop Rack Installation


Pallet racking allows you to make better use of expensive warehouse space. Therefore, a good design is an important step in making a warehouse profitable. Warehouse racking, on the other hand, must be correctly installed. Maintaining a safe warehouse environment through proper installation remains critical.



Ironstone specializes in warehouse storage systems and material handling solutions, and pallet rack installation is only one of the services we provide to harvest the most out of your industrial shelving investment. Our warehouse rack installation service removes the stress and troubles from your racking project by ensuring that your system is installed accurately and efficiently. Most importantly, you're busy — you have other stuff to do — so leave your warehouse rack installation to us.



High Capacity Heavy Duty Teardrop Steel Rack for Industrial Storage 6



What Can Ironstone Do For You?



1) Professional Design and Layout


Ironstone has professional racking designers with decades of experience to help our customers optimize storage space usage, ensuring that the storage system meets your needs as well as achieves your long-term goals.




2) Skillful manufacturing


With more than 20 years of experience, Ironstone has 150 skilled workers as well as a complete set of advanced production equipment. We are capable of providing you with high-quality racks at lower costs.




3) Fast Shipment


After production, we can arrange the delivery of well-packed racking products to your warehouse in excellent condition within the agreed timetable.




4) Quick Installation


We have a well-trained installation team. When it comes to the stage of installation, our experienced staff will install your racking according to the design. Before handing over the final project to you, we shall make every effort to ensure that the installation of the whole racking system is finished without any defects.
