High Compatible Steel Storage Rack With US Teardrop Rack, Europe And Australia Standard

High Compatible Steel Storage Rack With US Teardrop Rack, Europe And Australia Standard
Features Gallery Product Description Request A Quote
Product: High Selectivity Racking System
Components: Uprights, Beams, Braces, Protectors, Base Plates, Etc
Dimension: H:2~16.5Mts,Depth: 0.6~1.5Mts, Width: 1~3.9Mts, Customizable As Request
Load Capacity: 500kgs~4000kgs/Layer, 4000kgs~30000kgs/Bay
Certification: FEM Standards
Services: Free CAD Design, All-round After-sale Services
Pitch: 50 Mm, 50.8 Mm, 76.2 Mm
Brand: Ironstone, OEM/ODM Available
Hooks: 3 To 5 Hooks Available
Color: RAL5017(Blue), RAL2004(Pure Orange), RAL1037(Safety Yellow), Or Custom Color As Request
Materials: High Strength Steel/American Standard Steel
High Light:

Selective Racking System With Adjustable Beams


Q355B Steel Selective Pallet Racking


FEM standards Selective Pallet Racking

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-S
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

High Selectivity Steel Racking Storage System With Adjustable Beams



Steel storage systems designed for pallet racks are manufactured from roll-formed steel offering high selectivity. Suitable for various products of various sizes, Ironstone is a professional racking solution supplier that has been devoted to this area for over 20 years.


What we provide are not only high-quality steel racks but also all-round services including design, manufacture, shipping, delivery, and installation. Both bolted and welded frames are available with sturdy and durable beam-to-uprights connections.



                      High Compatible Steel Storage Rack With US Teardrop Rack, Europe And Australia Standard 0



Standard pallet rack specifications


Name Pallet rack Material US standard steel
Shelf levels 2~15 tiers per shelving unit Color Green, Orange, Blue, Yellow, Custom
Upright Frame Height 2500mm~15000mm Weight Capacity 500~3000kg per level
Beam Width 1000mm~3900mm Frame Depth 700mm~1500mm
Finish Epoxy powder coated for corrosion prevention
Usage Cargoes Storage, Palletized loads production
Package Plastic stretch film, corrugated paper, cartons, wooden bars, crates, metal strips, etc.
Accessories Bolts and nuts, Upright protectors, decks, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days as per order quantity
Assemble & installation Detailed assembly instructions are available




Upright Sizes


76.2*76.2, 80*70, 90*70, 100*70, 120*95mm


Hole Pitch


50mm, 50.8mm, 76.2mm
Step Beam Sizes


Beam Height: 2.5'', 3.0'',3.5'',4.0'',4.5'',5.0'',5.5'',6.0''

Thickness: 16GA-14GA



Box Beam Sizes


80*50, 90*50, 100*50, 110*50, 120*50, 130*50, 140*50, 160*50mm


Upright Thickness


1.8,2.0,2.5,2.75,3.0 mm


Beam Thickness


1.5,1.8,2.0 mm


Frame Height


Up to 12000mm


Beam Length


1000mm to 3900mm


Load Capacity


500-4000kg/Beam, 6000-25000kg/Frame



Ironstone selective pallet racks provide a wide range of storage capacity choices with improved space utilization. Using only high-strength high-quality steel, Ironstone storage equipment is certified to satisfy the strictest requirements in the International market.
In terms of beams, there are also a lot of options: step beams, box beams and close box beams. Among all of that, it's easy for you to find proper material thicknesses and section sizes that accommodating your storage load capacity. Connected by safety locks and pins, uprights and beams form a safe and stable structure protected by plenty of protectors.

Selective pallet rack can store one pallet, two pallets, or three pallets in one beam position. In each beam level, proper space should be left for safe and efficient material handling between pallet loads and upright frames.



                        High Compatible Steel Storage Rack With US Teardrop Rack, Europe And Australia Standard 1



Ironstone pallet rack features



​1. ​Quick and easy assembly.


2. Optional pitch distances.


3. Customized colors, blue uprights, and orange beams are more commonly used.


4.  Rigid wall spacer, galvanized or powder coated.


5. Column guard, frame protector, and optional wire decks with vivid color.


6. RMI R-Mark certification.


7. Anchoring bolts.


8. Durable wire mesh decks, steel panels, and other supportable components.



More Product Details



High Compatible Steel Storage Rack With US Teardrop Rack, Europe And Australia Standard 2





Q1:Does all racks produced by your company?


A1: Yes, we're a direct manufacturer with over 20 years of experience, main products of us include Pallet Racking, Shelving, Radio shuttles, Cantilever, Mezzanines, etc. All products are 100% produced by ourselves.


Q2: Where is your company located?


A2: Our factory is located in Jiangning District, Nanjing, Jiangsu, China, close to Nanjing Port, convenient for delivery 90,000 sqm production plant, which enables a strong production capacity and stable quality.


Q3: What certification do your products pass?


A3: We're ISO9001 certificated company. Rack systems are strictly designed and produced based on CE and AS4084:2012 standards for storage racks, and comply with FEM and RMI standards.


Q4: How long of your warranty period?


A4: We afford a 5-year warranty and lifetime insurance services for all racking products. For any quality issues caused by the quality of products, we'll provide free parts for replacement.


Q5: Are you able to provide installation service?


A5: We have a mature installation team with rich project experience. For some complicated cases, our engineer could come to the project site and help clients with installation work. Normally, we can offer solutions for your problem through email, mob, and video calls within 24 hours.
