Industrial Gravity-driven Carton Flow Shelf Racking for Convenient Storage

Industrial Gravity-driven Carton Flow Shelf Racking for Convenient Storage
Features Gallery Product Description Request A Quote
Name: Carton Flow Picking Unit System
Material: High Strength Steel/American Standard Steel
Color: RAL Code: Blue, Orange, Yellow, Grey, White, Etc.
Usage: Hand Picking Items
Dimension: Height:1.5~3.0m,Depth: 0.45~1.2m, Width: 1~3.9m, Customizable As Request
Load Capacity: 200kgs~1000kgs/Layer, 1200kgs~6000kgs/Bay
Certification: RMI(R-Mark Certification)/ AS4084-2012 / CE / ISO9001
Services: Free CAD Design, ODM&OEM, Transportation, Project Installation, Systems Maintenance Etc.
High Light:

1500mm High Carton Live Storage Racks


Carton Live Storage Racks 300kg


300kg carton flow racking systems

Basic Infomation
Place of Origin: China
Certification: RMI, AS4084, ISO9001, CE, ISO 18001
Model Number: CF Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Effective FIFO Carton Flow Racking System for Hand Picking Units




Carton flow racking system is an efficient and flexible storage solution that is able to transport stored items to the pick up face without interruption. You can also easily adjust shelves and wheels to ensure the effective movement of all sized goods.



The carton flow racking system is flexible enough to allow changes and development of the warehouse layout, thanks to the fact that it can be built as a fixed unit or provided with lockable wheels. Alternatively, it can be integrated into any lower level of pallet racking, for example, below bulk storage.




Name Carton flow rack Material Steel
Shelf levels 2~12 tiers per shelving unit Color Customized
Height Customized
Weight Capacity 150~800kg per shelf
Width Customized
Depth Customized
Finish Epoxy Powder Coated Corrosion Prevention
Usage Cargoes/Boxes/Non-palletized product Storage
Package Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days according to order quantity
Assemble & installation Easy assemble with detailed instruction



Industrial Gravity-driven Carton Flow Shelf Racking for Convenient Storage 0



Benefits and Features of Carton flow Racking System:


  • Adjustable, ergonomic racks - for ultimate handling efficiency


  • Dividing and dispensing - so picking can take place without interruption on either side


  • High packing density for carton storage - means more floor space


  • Reduced transport distances and picking times


  • Simple and fast installation


  • Simple, modular system


  • Adjustable track width


  • Wheel tracks made of galvanized steel with guide rails for easy loading


  • Rollers are made of high-quality polyethylene


When to choose carton flow racking system?



In general, fast-moving products are picked directly from pallets, while slow-moving products belong to storage systems such as static racks. Carton flow systems and carton flow racks are suitable for the intermediate range of product movements.



As a rule of thumb, products suitable for carton flow are picked at least once a week, but no more than half a pallet of boxes in the same week.



Industrial Gravity-driven Carton Flow Shelf Racking for Convenient Storage 1



Carton flow racks greatly increase the efficiency of the warehouse by automatically organizing products and automatically turning stock. Long, straight dedicated lanes keep products organized and reduce labor costs. By reducing floor space by 22%, storage space can be increased by up to 60%, thus reducing building costs.



Typically, carton flow racking systems use about half the floor space that standard pallet racking does and the difference can be more dramatic with a multi-level system. The simplicity of a gravity-driven system requires less capital than an easy-to-maintain automated system.



Rear loading front picking helps with worker traffic flow and promotes a more efficient layout. Carton and case flow to the front picking aisle helps alleviate concerns about order fulfilment in e-commerce facilities and large distribution centres or multi-level picking modules.
