High Density Drive In Pallet Storage Rack System FIFO LIFO

High Density Drive In Pallet Storage Rack System FIFO LIFO
Features Gallery Product Description Request A Quote
Features: FIFO And LIFO
Name: Drive In And Drive Through Pallet Racks
Material: High Strength Steel
Usage Range: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
Dimension: H:2~16.5Mts,Depth: 2.1~10.5Mts, Width: 1.35~1.5Mts, Customizable As Request
Load Capacity: 500kgs~2000kgs/pallet
Certifications: R-Mark Certification/ AS4084/ CE / ISO9001
Safety Accessories: Wire Decks, Column Protectors, Pallet Supports, Etc.
Products Package: Steel Strip, Stretch Film, Corrugated Paper, Bubble Film, Plywood Pallets
Services: Free CAD Design, ODM&OEM, Transportation, Project Installation, Systems Maintenance Etc.
High Light:

Drive In Pallet Storage Rack


FIFO Pallet Storage Rack System


Q355 Pallet Storage Rack System

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-DI Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, plywood pallet, bubble film, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Cost-Effective And High-Density Drive In Pallet Storage Rack System


►Drive-in pallet racking is one of, if not the, most space-efficient storage systems manufactured by Ironstone. This type of pallet racking is ideal for storing goods purchased in large quantities or in bulk, as well as warehouses with slow stock rotational requirements. If storage capacity is critical to your warehouse facility, this system is an excellent choice. Eliminating aisles increases storage density at the expense of selectivity, as the first pallet into a lane is the last pallet out. This is not a disadvantage in applications where pallets are received and dispatched in batch quantities.


►Drive-in pallet racking allows users to maximize available space in your warehouse because service aisles are significantly reduced when compared to other pallet racking systems. Our high-density racking system provides maximum pallet storage capacity and uses pallet rails to transport the pallets, ensuring that each pallet is individually supported, preventing damage from crushing due to block stacking. Trucks can physically enter the racking lanes to deposit and retrieve pallets thanks to the pallet rails. To reduce the likelihood of racking damage, floor mounted guidance rails can be incorporated into the design.
►Drive-in racking systems are more common because they can be easily positioned with their backs to a wall, eliminating the need for an aisle to access the back side and saving a significant amount of aisle space. Drive-in systems are generally less expensive because they do not require fully braced bays or three columns of beams/bracing. There is also less risk because the system presents fork truck operators with a more uniform system.

High Density Drive In Pallet Storage Rack System FIFO LIFO 0

Details of Drive-in and Drive-through Racks


Name Drive in and drive through pallet rack system
Color Following RAL color system, customized color are available
Loading weight 1000kg-2000kg per pallet, customized load capacity
Material Cold-rolled steel or structural steel
Characteristic First in-Last out(FILO) for drive in, FILO and FIFO for drive-through
Standard accessories Safety protectors, bolts, nuts, safety pin
Components Upright frame(upright, horizontal bracing, diagonal bracing), beams, pallet rails


Drive-In versus Drive-Thru
The way pallets are stocked and picked differs between drive-in and drive-through pallet rack systems. The forklift will only load and unload pallets on one side of the racks with the drive-in system. The term "drive-in" refers to the fact that the truck enters the system from only one side. Drive-in pallet racking is best suited to a last in, first out (LIFO) system and products that do not require rapid movement.
Drive-through pallet racking involves the forklift loading pallets on one side and unloading pallets on the opposite side. In this system, the truck uses rails to unload and load product after driving into the racks themselves. Drive-through pallet racking is best suited to first in, last out (FILO) systems because it is useful for products that move quickly.

Benefits Of Drive-In Racking Systems



♦High-Density Storage


One of the primary, and oftentimes most important, advantages of a drive-in racking system is that it allows you to improve your density storage. It maximizes and adds value to your warehouse. This type of system has the potential to increase usable square footage. A properly optimized system can support 6-8 pallets deep.


♦Easy To Move, Change The Structure, And Upgrade As Needed


With a few training sessions, your employees and warehouse personnel will be able to manage this type of system with ease. Its cross-beam patterns are simple to follow. All of your employees, particularly your forklift drivers, require additional loading procedure training. Another significant advantage is that the system is easily upgradeable — with just a few tweaks, you can add more storage.


♦Warehouse Space Optimization


You can reconfigure your warehouse space with a drive-in racking system, trimming the fat and making it leaner and more efficient. Clients increased their storage space by 80% by switching to an optimized line and storage configuration. You can use less space if you have a versatile and densely oriented system with fewer aisles.


♦Great For Storing A Large Number Of Homogenous Materials


The versatility of a drive-in racking system has its limits — which doesn’t necessarily make it a con. Most of these systems are optimized for one type of product or material.


♦Low Maintenance And Low Assembly Costs


A drive-in racking system is extremely affordable and easy to assemble. Not only that, but due to its high quality and durable materials, it is exceptionally practical when it comes to maintenance.




Components of the Systems



Drive-in and drive-through pallet racking systems are comprised of uprights and rail beams. The uprights provide vertical support, and the rail beams are used for pallet storage that is extremely dense. In this system, product is stored both back-to-back and floor-to-ceiling. This means that on average, you can store seven times more products when compared to another pallet rack system. Drive-in and drive-through pallet racks can also be connected to a standard pallet rack or customized design.


High Density Drive In Pallet Storage Rack System FIFO LIFO 1


Design Specification for Warehouse Solution of Drive-in Racking System:



1). Dimensions of pallet & goods: Length× Width× Height;



2). Total weight of goods (including pallet);



3). Forklift maximum lifting height & net usable height in the warehouse;



4). Forklift model & parameters;



5). Direction and requirements for goods moving in and out;



6). Building conditions of storage area in the warehouse;
