Corrosion Protection Drive in Storage Pallet Racks

Corrosion Protection Drive in Storage Pallet Racks
Features Gallery Product Description Request A Quote
Name: Drive In Denser Pallet Storage Racking
Feature: LIFO Stock Rotation For Bulky Products
Supports: Before Sale And After Sale Services
Color: RAL Code: Blue, Green, Orange, Yellow, Grey, Galvanization, Etc.
Certifications: R-Mark Certification/ AS4084/ CE / ISO9001
Dimension: H:2~16.5Mts,Depth: 2.1~10.5Mts, Width: 1.35~1.5Mts, Customizable As Request
Material Type: High Strength Steel/American Standard Steel
Products Package: Steel Strip, Stretch Film, Corrugated Paper, Bubble Film, Plywood Pallets
Usage Range: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
High Light:

LIFO Drive In Racking System


Drive In Racking System AS4084


LIFO drive in warehouse racking

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-DI Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, plywood pallet, bubble film, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Warehouse Space Saving Drive In Racking System For Safe Pallets Storage And Picking



Space-saving drive-in pallet racks are designed with upright frames and supported rails for pallet loads storing and picking. The deep storage bay and drive-in construction feature determine that the potential safety hazard is greater than other racking systems.




Specifications of drive-in pallet racks



Type Warehouse drive-in pallet racking system
Color RAL color system, customized
Load Capacity Customized load ranged from 1000kg-2000kg per pallet
Material Roll-formed steel with high quality
Working principle First in-Last out(FILO)
Standard accessories Safety protectors, bolts, nuts, safety pin
Component Upright frame(upright, horizontal bracing, diagonal bracing), beams, pallet rails




Corrosion Protection Drive in Storage Pallet Racks 0




The following has listed some possible safety concerns in the drive-in racking system:




► Drive in racking structure damage and collapse resulted from forklift crash.



► Loose external pallet package.



► Uneven placement of pallet loads on support rails.



► Misaligned frames arrangement.



► Improper operation of the forklift driver.



► Overloaded pallet loads that exceed the maximum load capacity of the rails or the racks.



► No proper safety protective accessories installed.



When it comes to warehouse safety, we would like to cover mainly four aspects: human safety, product safety, rack structure safety and related equipment safety. In the drive in racking system, forklift has to enter into the racks for product storing and picking which is relatively difficult to operate.



For safe and accurate placement, pallets in good condition should be evenly rested on the two supporting rails covering the medium space. To guarantee structural integrity, the distance between two rails should be accommodated to proper pallet sizes in case of pallet falling or rails overloading.



Corrosion Protection Drive in Storage Pallet Racks 1




Effective factors that contribute to drive in rack safety:




►Pallets for products should be intact and undamaged for safe operation.



►The design of the drive-in rack should be implemented by professional rack engineer fully considering the warehouse layout, storage demands, pallet load sizes and weights before production.



►The racks should be engineered by qualified manufacturers with strict quality management.



►The project for the drive-in pallet racking systems installation should be carried out by a professional installation crew and satisfy local building codes and fire safety regulations.



►Forklift operators of the drive-in pallet rack should be well-trained with both skills and sense of security.
