Preeminent Double Deep Racking With Variety Loading Capacity

Preeminent Double Deep Racking With Variety Loading Capacity
Features Gallery Product Description Request A Quote
Name: Double Deep Pallet Racking System
Material: High Strength Steel-/American Standard Steel
Color: Customizable
Usage: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
Dimension: Height:2~16.5M,Depth: 0.6~1.5M, Width: 1~3.9M, Customizable As Request
Load Capacity: 500kgs~4000kgs/Layer, 4000kgs~30000kgs/Bay
Certification: RMI / AS4084-2012 / CE / ISO9001
Use: Warehouse Rack,Industrial,Supermarket
Structure: Easy Assemble,Knock-down,Assembled Freely
High Light:

Warehouse Rack Pallet Racking System


500kgs/Layer Pallet Racking System

Basic Infomation
Place of Origin: China
Certification: RMI, AS4084, ISO9001, CE
Model Number: HDDD Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, Cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Double Deep Adjustable Warehouse Rack Pallet Racking System




Two pallets can be kept deep in a double deep rack, or four pallets can be stored deep. Double entry racks reduce aisle-to-rack ratio while increasing pallet selectivity, resulting in enhanced storage density.50% rapid pallet access provides for proper stock rotation based on FILO (First In Last Out) and maximizes the use of all available locations. When each SKU has many pallets, this strategy works effectively.



The system requires a one-of-a-kind reach truck with dual pantograph or sliding fork attachments. Truck lift heights are limited by the load to around 9 meters. Upper levels can be installed with guide rails to assist forklift drivers in locating pallets; they help avoid fork truck operator error and unintentional collision damage. Double Deep Racking is most suitable for Cool Rooms, Dry Stores, and where there are multiple pallets of the same stock.





1. As the rack aisle ratio changes from Selective racking, storage density increases.


2.50% instant availability with good stock rotation.


3. At least 90% of available venues are used.


4. Secure and safe handling with the bottom pallet, which is normally off-ground.


5. The ability to use double deep handling equipment for additional purposes.


6. Ideal when each SKU has multiple pallets.




Name Double Deep Pallet racking Material High Strength Steel-/American Standard Steel
Beam levels 2~15 tiers per bay rack Color (RAL Code) Green, Orange, Blue, Yellow, Etc.
Upright Frame Height 2500mm~15000mm Weight Capacity 500~3000kg per level
Beam Width 1000mm~3900mm Frame Depth 700mm~1500mm
Finish Epoxy Powder Coated for corrosion prevention
Usage Cargos Storage
Package Plastic stretch film, corrugated paper, Cartons, wooden bars, crates, metal strips, etc.
Accessories Bolts and nuts, Upright protectors, decks, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days as per order quantity
Assemble & installation Detailed assembly instructions are available as well as dispatching installation engineer for project installation at the site.



 Preeminent Double Deep Racking With Variety Loading Capacity 0



This technique is ideal when distribution centers have many pallets of the same product that must be kept together quickly. Customers can specify when this racking system requires the use of pallet guides, which are created by pushing pallets into position with a length of angle guide, allowing the pallet to be square and sit in the correct position while also allowing the driver to safely load all of the pallets without the senior staff seeing behind them.


                                     Preeminent Double Deep Racking With Variety Loading Capacity 1



Characteristics of Double Deep Pallet Racking System:



High storage density that increases floor space utilization by 55%.



►Immediate accessibility to 50% of SKUs.



►Adjustable beam levels to re-configure the size of the pallets.



►Very cost-effective.



►Variety of frame and beam capacities to fit your requirements.



Ironstone supplies a whole package of rack system products and services. We combine our superior selection of high-quality products with professional, first-rate service. We can help you select the right options for your particular storage needs and provide additional support to help you install your warehouse racking system. Contact us to get your personal design now!
