CE /RMI Approved Robust Metal Drive In Storage Racking

USD $0.85/KG
CE /RMI Approved Robust Metal Drive In Storage Racking
Features Gallery Product Description Request A Quote
Name: Drive In Racking
Feature: LIFO Stock Rotation For Bulky Products
Supports: Before Sale And After Sale Services
Color: RAL Code: Blue, Green, Orange, Yellow, Grey, Galvanization, Etc.
Certifications: R-Mark Certification/ AS4084/ CE / ISO9001
Dimension: H:2~16.5Mts,Depth: 2.1~10.5Mts, Width: 1.35~1.5Mts, Customizable As Request
Material Type: High Strength Steel/American Standard Steel
Products Package: Steel Strip, Stretch Film, Corrugated Paper, Bubble Film, Plywood Pallets
Usage Range: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
High Light:

FILO Drive in Pallet Racking


Warehouse Drive in Rack Systems


CE Approved Drive in Racking

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-DI Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, plywood pallet, bubble film, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

CE/RMI Approved Robust Metal Drive-in Storage Racking




Drive-in or drive-through racking is a type of storage that improves warehouse area utilization at the expense of instant accessibility. These racks have a maximum depth of twelve pallets and a maximum height of six to seven pallets, but selectivity decreases as systems get more intricate.



Drive-in racking is best used in warehouses that handle large amounts of inventory, while in certain circumstances, only a portion of a warehouse is converted to this sort of storage for the best results. You can learn more about the benefits and downsides of drive-in pallet racking in the paragraphs that follow, as well as if this type of racking is a good fit for your storage needs.



Specifications of Drive-in Pallet Racks



Type Warehouse drive-in pallet racking system
Color RAL color system, customized
Load Capacity Customized load ranged from 1000kg-2000kg per pallet
Material Roll-formed steel with high quality
Working principle First in-Last out(FILO)
Standard accessories Safety protectors, bolts, nuts, safety pin
Component Upright frame(upright, horizontal bracing, diagonal bracing), beams, pallet rails





CE /RMI Approved Robust Metal Drive In Storage Racking 0

Basic Characteristics of Drive-in Racking System




Instead of beams, a drive-in racking system uses rails to support each row of pallets. It is nicknamed a "drive-in" rack because a forklift operator can drive into the racking system and place the first pallet at the end of a lane. Then, he can set a second pallet directly behind the first one, and so forth. Pallet removal follows a similar procedure, with the notable distinction that the operator must first move any pallets in front of a pallet that needs to be removed from the back of the row.



As a result, the system is set up using FILO (First-In-Last-Out) access, which may not be ideal for some businesses or warehouses where order picking is done from pallets. Drive-in racking, on the other hand, can save a lot of room and is perfect for storing numerous pallets per SKU (stock-keeping unit) for the same product.




Components of drive in racks


Drive-in Racking: Uses and Advantages



Similar to block stacking, drive-in racking is a very high-density storage solution that may be constructed higher and is more likely to maintain the integrity of the stock. Its benefits and usage include:



♦ Increased Storage Capacity


One of the densest storage methods is drive-in pallet racking. No other type of storage can equal its capacity, which is up to 12 pallets deep and 7 pallets high. The latter also frees up more floor space because fewer aisles are required to run such a system.



♦ FIFO Access is Possible


For warehouses that deal with goods with a short shelf life, a typical drive-in racking system with one or two entries allows accessibility on a FILO basis. However, drive-through racking is a practical choice for businesses that handle perishable material since, when set up correctly, it enables FIFO inventory control.





CE /RMI Approved Robust Metal Drive In Storage Racking 2




♦ Ideal for Temperature-controlled Storage Spaces



Because maintaining temperature control in a warehouse may be highly expensive, as the warehouse manager, you should make the most of every square inch of space. Drive-in racks are the best storage option currently available for helping you accomplish that.



♦ Cost-effective


In terms of cost per pallet, a drive-in racking system is among the cheapest storage options. When space is limited, it can assist warehouse managers to save money and ensure that expensive portions of the warehouse, like those that offer refrigeration, are utilized to their fullest potential.




            CE /RMI Approved Robust Metal Drive In Storage Racking 3




All things considered, drive-in pallet racks are perfect for warehouses that deal with a lot of pallets per SKU but can't use block stacking due to concerns about product quality. They allow the deposit of huge loads and are also cost-effective when used in conjunction with cold or frozen storage.




Drive-in Racks from Ironstone



Drive-in racking is appropriate for particular uses, like the majority of other warehouse storage options. If you're unsure whether this kind of system is best for your storage area yet, get in touch with Ironstone right away to go through the specifics of your project.



We at Ironstone have a wealth of experience creating and delivering all kinds of storage solutions to clients all over the world. We are particularly qualified to assist you in identifying and putting into practice the optimum solution for your warehouse.




Project Cases




CE /RMI Approved Robust Metal Drive In Storage Racking 4 CE /RMI Approved Robust Metal Drive In Storage Racking 5




Questions You May Care About:



Q1:Does all racks produced by your company?


A1: Yes, we're a DIRECT manufacturer with over 20 years of experience, main products of us include Pallet Racking, Shelving, Radio shuttles, Cantilevers, Mezzanine, etc. All products are 100% produced by ourselves.



Q2: Where is your company located?


A2: Our factory is located in Jiangning District, Nanjing, Jiangsu, China, close to Nanjing Port, convenient for delivery. 90,000 sqm production plant, which enables a strong production capacity and stable quality.



Q3: What certification do your products pass?


A3: We're ISO9001 certificated company. Rack systems are strictly designed and produced based on CE and AS4084:2012 standards for storage rack, and comply with FEM and RMI standards.



Q4 How long of your warranty period?


A4: We afford 10-year warranty and lifetime insurance services of all racking products. Any quality issues that caused by the quality of products, we'll provide free parts for replacement.



Q5: Are you able to provide installation service?


A4: We have mature installation team with rich project experience. For some complicated cases, our engineer could come to project site and help clients for installation work. Normally, we can offer solutions for your problem through email, mob and video call within 24 hours.
