Free CAD Design American Teardrop Pallet Racking With Shelving For Storage
The name teardrop is derived from the punched holes in the column whose shapes look like a teardrop. Connected with step beams to form the storage unit, this kind of racking system is the most commonly used type in the American market, so it is called the American standard pallet rack system.
Specification Reference
| Name | Teardrop (US) Pallet Rack | Material | American standard steel |
| Depth | 24"-60" | Weight Capacity | 1000-7000lbs/beam level |
| Width | 48"-156" | Height | 96”-432” or Customized |
| Frame Structure Type | Welded & Bolted 3"*3" Upright frame with Seismic Baseplate | ||
| Beam Type | 2.5"-6.25" Step Beam | ||
| Beam Connector Type | SP & SL Safety Locker | ||
| Surface finish | Powder coating &Galvanized | ||
| Application Environment | Normal Temperature or Cold Room (Max -40C) | ||
| Certification | RMI Certification, ISO9001, CE | ||
| Free Sample | Available | ||
| OEM | Available | ||
Step beams dimensions
| Step-beam size | 3", 3.5", 4", 4.5", 5", 5.5",6", 6.25" |
| Length | 60", 72", 84", 96", 108", 120", 132", 144" |
| Thickness | 16Ga, 15Ga, 14Ga |
The teardrop pallet rack is very stable and sturdy with simple beam-to-frame structure using high-strength steel with corrosion protection. Enduring long-time usage with a lot of merits, the teardrop pallet racking system also has a lot of accessories to match.
Merits of teardrop pallet rack include:
• Full selectivity and direct access to individual pallets.
• Simple and easy material handling method with only one pallet deep.
• Flexible and adaptable to any size and weight product.
• Long-span beams with enough storage space are very cost-effective.
• Interchangeable components manufactured with different suppliers.
• Fast installation and maintenance-free design.
Teardrop pallet rack can be matched with shelves to form a flat storage surface for unpalletized items. Wire mesh decks, plywood, and metal panel can all be used to create a stable storage shelving system.
