Teardrop Style Warehouse Pallet Rack

Teardrop Style Warehouse Pallet Rack
Features Gallery Product Description Request A Quote
Color: RAL5017(Blue),RAL2004(Pure Orange) RAL1037(Safety Yellow), Or Custom Color As Request
Usage Range: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
Dimension: H:2~16.5Mts,Depth: 0.6~1.5Mts, Width: 1~3.9Mts, Customizable As Request
Load Capacity: 500kgs~4000kgs/Layer, 4000kgs~30000kgs/Bay
Certifications: RMI / AS4084-2012 / CE / ISO9001
Safety Accessories: Wire Decks, Column Protectors, Pallet Supports, Etc.
Products Package: Steel Strip, Stretch Film, Corrugated Paper, Bubble Film, Plywood Pallets
Services: Free CAD Design, ODM&OEM, Transportation, Project Installation, Systems Maintenance Etc.
Materials: High Strength Steel/ American Standard Steel
High Light:

30000kgs Heavy Duty Pallet Racking


Industrial Pallet Racking For Warehouse ODM


ODM Warehouse Storage System

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-SPS
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, Cartons, Plywood Pallet, bubble film, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Teardrop Style Warehouse Pallet Rack

As the most commonly-used warehouse pallet rack system, Selective pallet racking is known for its 100% direct access to every pallet position with one-time loading and unloading as well as providing efficient utilization of f space in your facility. There are two main parts that consist of selective pallet racking systems, that is, upright frame and cross Beam.



Name Pallet rack Material  US standard steel
Shelf levels 2~15 tiers per shelving unit Color  Green, Orange, Blue, Yellow, Custom
Upright Frame Height 2500mm~15000mm Weight Capacity 500~3000kg per level
Beam Width 1000mm~3900mm Frame Depth 700mm~1500mm
Finish Epoxy powder coated for corrosion prevention
Usage Cargoes Storage, Palletized loads production
Package Plastic stretch film, corrugated paper, cartons, wooden bars, crates, metal strips, etc.
Accessories Bolts and nuts, Upright protectors, decks, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days as per order quantity
Assemble & installation Detailed assembly instructions are available


               Teardrop Style Warehouse Pallet Rack 0

It’s a good option if a variety of cargoes/SKUs need to be stored in your warehouse while taking warehouse pallet rack systems as a storage solution, it has the following several Advantages:


►All palletized products can be picked or stored directly, there will be no obstacles to reaching the objective pallet positions.


►Inventory management is simple as every pallet position is individual one with one more procedure.


►More accommodating to different measurements and weights of each load.




 Teardrop Style Warehouse Pallet Rack 1

Teardrop Style Warehouse Pallet Rack 2

Teardrop Style Warehouse Pallet Rack 3

Teardrop Style Warehouse Pallet Rack 4



Selective pallet rack component



Teardrop Style Warehouse Pallet Rack 5




Typical Selective pallet racking layout in the warehouse should be single rack run along the wall and back-to-back rack rows built in between, for the aisle width where accommodate forklift to load and unload pallet products on racks should be conventional based on the following factors:

1.  Pallet load size
2.  Forklift type
3. location of warehouse structural pillars


                 Teardrop Style Warehouse Pallet Rack 6Teardrop Style Warehouse Pallet Rack 7





Q1:Does all racks produced by your company?

A1: Yes, we're a direct manufacturer with over 20 years of experience, main products of us include Pallet Racking, Shelving, Radio Shuttle, Cantilever, Mezzanine, etc. All products are 100% produced by ourselves.


Q2: Where is your company located?

A2: Our factory is located in Jiangning District, Nanjing, Jiangsu, China, close to Nanjing Port, convenient for delivery. 90,000 sqm production plant, which enables a strong production capacity and stable quality.


Q3: What certification do your products pass?

A3: We're ISO9001 certificated company. Rack systems are strictly designed and produced based on CE and AS4084:2012 standards for storage racks, and comply with FEM and RMI standards.


Q4 How long of your warranty period?

A4: We afford a 10-year warranty and lifetime insurance services for all racking products. Any quality issues that are caused by the quality of products, we'll provide free parts for replacement.


Q5:Do you provide the samples?

A5:We can provide the product samples for you to test. Samples can be transported by sea, land, and air.


Q6: When is the delivery time?

A6: It usually takes 25 to 30 days. But the exact delivery time is different for different order quantities.
