RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage

1*20ft
MOQ
USD$0.85/KG
Price
RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Single Selective Pallet Racking
Color: RAL5017(Blue),RAL2004(Pure Orange), RAL1037(Safety Yellow), Or Custom Color As Request
Dimension: H:2~16.5Mts,Depth: 0.6~1.5Mts, Width: 1~3.9Mts, Customizable As Request
Load Capacity: 500kgs~4000kgs/Layer, 4000kgs~30000kgs/Bay
Certification: RMI / AS4084-2012 / CE / ISO9001
Services: Free CAD Design, All-round After-sale Services
Pitch: 50mm, 76.2mm
Brand: Ironstone, OEM/ODM Available
Usage: Distribution Centers, Cooler Rooms, Freezers, Industrial Warehouses
Beam Types: Step Beam, Box Beam
Accessories: Upright Protectors, Support Bars, Row-spacers
Materials: High Strength Steel/American Standard Steel
High Light:

Q355 Single Selective Pallet Racking

,

Pallet Racking For Cold Storage RAL

,

Q355 single deep selective rack

Basic Infomation
Place of Origin: Jiangsu, China
Brand Name: Ironstone
Certification: RMI, AS4084, ISO9001, CE
Model Number: HD-S
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

 Industrial High Strength Selective Pallet Racking Systems







Selective pallet racking, the simple but functional warehouse storage system, offers direct access to each pallet and also full selectivity. With an acceptable price and easy-to-operate structure, selective racking system becomes the center of the attention of warehouse owners and business runners in the world.





Details of Warehouse Pallet Rack





Name Pallet rack Material  US standard steel
Shelf levels 2~15 tiers per shelving unit Color Green, Orange, Blue, Yellow, Custom
Upright Frame Height 2500mm~15000mm Weight Capacity 500~3000kg per level
Beam Width 1000mm~3900mm Frame Depth 700mm~1500mm
Finish Epoxy powder coated for corrosion prevention
Usage Cargoes Storage, Palletized loads production
Package Plastic stretch film, corrugated paper, cartons, wooden bars, crates, metal strips, etc.
Accessories Bolts and nuts, Upright protectors, decks, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days as per order quantity
Assemble & installation Detailed assembly instructions are available





RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 0





To master the knowledge of customizing your proper size pallet racks thoroughly, Ironstone will show you some details of the major components forming selective racking systems.





Upright Frames



Upright frames, consisting of columns and bracings, can be customized with different heights and dimensions. Produced with cold-formed steel using bending machines, our uprights have variable material thickness and sections for ranges of loading capacities.





               RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 1RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 2





Beams



For standard upright columns, box beams are commonly used as the major weight-bearing components produced with safety pin connectors.





                RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 3



Box beams are available in a comprehensive range to cover most loading requirements. Beam section height is available from 80~160mm, and steel thicknesses are available in 1.5, 1.7, and 2.0mm.





Secondary Support



In selective pallet racking, pallet support bars and shelves are often added on horizontal beams offering secondary support for palletized and non-palletized products.



Pallet support bars are placed at the interval part of two beams facilitating the safety and accuracy of pallet storage and picking.





                 RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 4





The commonly used shelves are wire mesh decks, plywood shelves, and galvanized panels.





                     RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 5



Selective pallet racks made of high-strength high-quality steel, are highly recommended for you with their superb selectivity, accessibility, variability, flexibility, safety, productivity, and cost-saving quality.







                         RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 6



  • Our product production process and packaging





  • RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 7

RMI/AS4084 Certified Industrial Selective Pallet Rack For Warehouse Storage 8

  •
