Stainless Light Duty Rivet Shelving Rack

Stainless Light Duty Rivet Shelving Rack
Features Gallery Product Description Request A Quote
Name: Rivet Shelving
Material: High Quality Steel
Color: White, Blue, Gray, Orange
Logo: Customized Logo With Brand Name
Dimension: H:1.5~3.0Mts,Depth: 0.45~1.2Mts, Width: 1~3.9Mts, Customizable As Request
Load Capacity: 200 Kg~1000 Kg Per Layer
Certification: RMI(R-Mark Certification)/ AS4084-2012 / CE / ISO9001
Services: Free CAD Design, ODM&OEM, Transportation, Project Installation, Systems Maintenance Etc.
High Light:

Q355 Rivet Shelving Rack


Stainless Rivet Shelving Rack


RMI Picking Shelving

Basic Infomation
Place of Origin: China
Certification: RMI, AS4084, ISO9001, CE
Model Number: LSS Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

Stainless light-duty Rivet shelving rack



Rivet shelving is one of the most cost-effective DIY (Do It Yourself) storage systems. This adaptable system requires no bolts and can be assembled quickly. Depending on the beam length, spacing, and shelving material, it can hold up to 450 kg per level. Rivet racks use a minimum of components, and the core of the system is the columns and racks made of high-quality steel. Our ironstone uses the best materials and the simple structure of a fully automated production line to provide consistently high-quality products that are quick and easy to install.


Stainless Light Duty Rivet Shelving Rack 0



​Feature and Advantages of Stainless light-duty Rivet shelving rack

♦A quick and cost-effective method of storing goods.

♦Rivet shelving racking system is light in weight yet very strong and can store light to heavy-weight products straightforwardly, and the stainless steel material makes it more durable.

♦It is possible to install it as a standalone manually operated storage system or as part of a larger fully automated system.
♦Used for archiving and storing small parts in warehouses.
♦Very common in the home and garage.
♦Adjustable beam levels to meet individual requirements.
♦Flexible and adaptable, with a wide range of storage applications.



Rivet Shelving Specifications Reference



Item Spec (mm) Thickness (mm) Capacity (kg)
Angle post 32*32 1.0-2.0 500-1000
35*35 1.0-2.0 500-1000
38*38 1.0-2.0 500-1000
47*47 1.0-2.0 500-2000
Double rivet beam 50*15 0.8-2.0 100-250
55*15 0.8-2.0 100-250
67*21 0.8-2.0 100-250
Single rivet beam 25*25 1.0-2.0 50-150
Shelf levels 2~12 tiers per shelving unit
Color Gray, White, Black, Blue, Etc.
Finish Epoxy Powder Coated for corrosion prevention
Usage Cargos Storage
Package Plastic stretch film, corrugated paper, Cartons, wooden bars, crates, metal strips, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days according to the order quantity
Assemble & installation Detailed assembly instructions are available

More Product Details


Stainless Light Duty Rivet Shelving Rack 1



Rivet Shelving Main Component


Stainless Light Duty Rivet Shelving Rack 2


Other Optional Accessories


Stainless Light Duty Rivet Shelving Rack 3

Potential Applications


•Light-duty rivet shelving system ideal for use in the storeroom, workshop, or warehouse environments.


•Suitable for general shelving, storage, or archiving.



You can provide us with the following information so that we can give you a better service:


1) Full details of size: L*D*H;

2) Loading capacity of each layer;

3) RAL color you require;

4) Accessories you need;

5) Drawing (if available)&OEM design are welcome;


Project  Cases


Stainless Light Duty Rivet Shelving Rack 4 Stainless Light Duty Rivet Shelving Rack 5





Q1:Does all racks produced by your company?

A1: Yes, we're a direct manufacturer with over 20 years of experience, main products of us include Pallet Racking, Shelving, Radio shuttles, Cantilever, Mezzanines, etc. All products are 100% produced by ourselves.


Q2: Where is your company located?

A2: Our factory is located in Jiangning District, Nanjing, Jiangsu, China, close to Nanjing Port, convenient for delivery 90,000 sqm production plant, which enables a strong production capacity and stable quality.


Q3: What certification do your products pass?

A3: We're ISO9001 certificated company. Rack systems are strictly designed and produced based on CE and AS4084:2012 standards for storage racks, and comply with FEM and RMI standards.


Q4 How long of your warranty period?

A4: We afford a 10-year warranty and lifetime insurance services for all racking products. For any quality issues caused by the quality of products, we'll provide free parts for replacement.


Q5: Are you able to provide installation service?

A5: We have a mature installation team with rich project experience. For some complicated cases, our engineer could come to the project site and help clients with installation work. Normally, we can offer solutions for your problem through email, mob, and video calls within 24 hours.



Q6:Do you provide the samples?

A6:We can provide the product samples for you to test. Samples can be transported by sea, land, and air.



A7:We can provide OEM ODM service, we know that brand owners care about the quality of products, so our products from the choice of materials, and product style design will be strictly in accordance with your product design drawing design. At the same time, we have a professional research and development team. If you need a product with special functions and requirements, you can also communicate your ideas with us.

Should any issue you are concerned about, feel free to contact me before and after-sales.
