ODM Medium Duty Long Span Shelving

ODM Medium Duty Long Span Shelving
Features Gallery Product Description Request A Quote
Name: Long-span Shelving
Material: High Strength Steel
Color: RAL Code: Blue, Orange, Yellow, Grey, White, Etc.
Usage: General Warehouse Distribution, Logistics, Cold Warehouse Storage, E-Commerce, Manufacturing, Food&Beverage, Retail, 3PL, Automotive, Record Storage
Dimension: H:1.5~3.0Mts,Depth: 0.45~1.2Mts, Width: 1~3.9Mts, Customizable As Request
Load Capacity: 200kgs~1000kgs/Layer, 1200kgs~6000kgs/Bay
Certification: RMI(R-Mark Certification)/ AS4084-2012 / CE / ISO9001
Services: Free CAD Design, ODM&OEM, Transportation, Project Installation, Systems Maintenance Etc.
High Light:

ODM Long Span Shelving


1.5m High Heavy Duty Pallet Shelving


ODM Medium Duty Pallet Racking

Basic Infomation
Place of Origin: China
Certification: RMI, AS4084, ISO9001, CE
Model Number: LSS Model
Payment & Shipping Terms
Packaging Details: Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Delivery Time: 15~25 days
Payment Terms: L/C, T/T
Supply Ability: 3000 Tons per month
Product Description

 Customized Long Span Shelving for Hand Picking Product Storage








Have you ever met storage problems of variable sizes product, such as small items, medium sized but non-palletized loads or irregular shaped goods that are easy to fall or scatter?



Long-span shelving is a good choice for your awkward situation. Fixed with longer length decks and shelves, long-span shelving offers a flat surface for product placement. Suited to light-duty or medium-duty hand-picking loads, long-span shelving can be configured with a lot of appearances, dimensions and materials to fit a wide range of products.




Here are some parameters of long-span shelving for reference.


Name Long-span shelving Material Steel
Shelf levels 2~12 tiers per shelving unit Color Customized
Height Customized
Weight Capacity 150~800kg per shelf
Length Customized
Depth Customized
Finish Epoxy Powder Coated Corrosion Prevention
Usage Cargos/Boxes/Irregular shapes/Non-palletized product Storage
Package Plastic stretch film, corrugated paper, cartons, wooden bars, crates, and metal strips, etc.
Certification RMI/AS4084-2012 /CE/ ISO9001
Delivery time 7~25 days according to order quantity
Assemble & installation Easy assembled with detailed instruction





Structure and Components



ODM Medium Duty Long Span Shelving 0




The basic structure of long-span shelving contains frames,beams,panels and accessories. The shelves materials can be chipboard, steel panels and wire decks as the following picture shows.




Features and Applications




► Long-span shelving can be very versatile with customized sizes and shelving material options, which can store small items to large ones.



► Long-span shelving has interchangeable components and accessories with adjustable panel height and distance.



► Long-span shelving is very cost-effective for industrial storage with great space utilzaiton.



► Long-span shelving offers direct access and clear vision for product handling process.



► Long-span shelving is easy to install and dismantle, saving a lot of operational trouble.




ODM Medium Duty Long Span Shelving 1




Long-span shelving are popular in the following areas which require reliable, flexible and extentable shelves for manul handling products.



► Industrial warehouse for medium duty loads



► Storage rooms for unpalletized products



► Distribution centers



► Supermarkets and grocery stores



► Pharmacy



► Electrical products



► Garment storage



► Automotive parts and components
